Automatic CNC Aluminum Corner Crimping Machine features two special operating heads, each equipped with masses containing two knives that can be adjusted for all crimping positions. These knives are independently adjustable and movable along the Y axis (profile length), Z axis (vertical), and X axis (crimping direction). Thanks to this flexibility, there is no need to change tools when working with different profile types. As a result, setup time and operational costs are significantly reduced.
CNC Control System
Strong and Durable Machine Body
The selected program recalls the profile from memory, and
the supports and pressing knives position themselves
automatically
Equipped with adjustable supports and pressing knives
tailored to the profile
The hydro-pneumatic pressing and crimping systems
operate synchronously
Standard 3 mm and 8 mm Pressing Knives
(Optional: Special Pressing Knives)
Maximum Pressing Height: 120 mm
(Optional: 180 mm Pressing Height)
7″ Touchscreen Display
3,5t Pressing Force
The knives have automatic movement capability along 12
axes: Y-axis (along the profile), Z-axis (up-down), and X-axis
(pressing direction); while the rear support stop moves
automatically forward-backward and up-down
There is no information about standard equipment. Please contact us for your requests.
There is no information about optional equipment Please contact us for your requests.
This product does not have video. Please contact us for your requests.
