PVC Sash Hardware Mounting Station

Technical specifications

• Designed for assembly all Tilt & Turn hardware systems on different types, various sizes of window & door sash profiles without tape measure and pencil using, without need for molds and templates, provides speedy, high quality and standard assembling.
• Sash Assembling Table (Adjustable Template not requiring the Mold change)
• Automatic centering system of window’s sash
• Automatic measurement of espagnolettes and scissors
• Punch for espagnolette and scissor stay cutting

Min. Profile Working Length 330 mm
Max. Profile Working Length 2500 mm
Min. Profile Height 30 mm
Min. Profile Width 50 mm
Screw dimensions to be used
Min: 3,9 mm x 16 mm / Max: 4,2 mm x 38 mm
Max. Profile Height 105 mm
Max. Profile Width 125 mm

Electrical Values 380-400V, 50hz, 3 ph
Total kW 3 kW

Air Pressure 6-8 bar
Air Consumption 250 lt/cycle
